Many of you have seen my videos of me using my Shapeoko 3 XXL CNC and have seen my custom waste board. Since I've gotten several messages about it I'm writing this blog post for everyone to access easily. Although the file is made for the XXL it can easily be modified for any size CNC you have.
Click The Button Below To Purchase From My Etsy Shop:
It helps support what i do so I can create more free content :)
Purchase the Myers Woodshop Wasteboard
You'll want to download this as it's preprogrammed for a 3/4 thick sheet of mdf at 31" x 31" (the max cutting area of a XXL).
When you open the file you'll be looking at the bottom of the waste board. The t-nuts come up from the bottom. The larger circle is the base (washer-like) part of the t-nut and the smaller hole is where the shaft of the t-nut will go through. I programmed the file to use the cutter that came with your machine, #201, 1/4 up-cut bit.
If you have a 1/8 bit it would be ideal to 'drill' the smaller holes with it. Generally, it is recommended to use a bit 1/3 of the size hole your going to create. If your having problem drilling the hole with the #201, use a 1/8 upcut bit.
You'll want to place the sheet at the very front of the machine against the metal lip and make sure it's centered. When you cut, you'll want to make sure that you use dust collection and wear breathing protection (I recommend the RZ Mask) because MDF dust is extremely fine and very harmful.
After it's done cutting the file, i predrilled and countersunk a few holes around the waste board we just cut to screw it to the waste board that came with the machine. Make sure you sink these screws at least 1/2 way through the material. You don't want to accidentally hit them with a bit! The 3/4 mdf we just cut with our hole pattern is called a supplemental waste board. Why don't we just replace the waste board that came with our machine? We do this because we will eventually mark up the board with through cuts and get to a point that it will need to be replaced. Its much easier to unscrew a piece of mdf and replace the smaller board than take the whole machine apart and end up having to re-square the machine. Unfortunately, You'll have to purchase a full 4x8 sheet of mdf to get the piece we need.
Once attached, you'll flip the board over so the t-nuts are on the underside. The bolts come through the top and thread into the t-nuts. I use 1/4-20 t-nuts, bolts, and washers.
1/4 - 20 T-Nuts - https://amzn.to/2KWDsx5
1/4 - 20 hex bolts - https://amzn.to/2UgneU5
1/4 - 20 washers - https://amzn.to/2KXoFST
